Jonard Tools - UST-540 - Universal Cable Stripping Tool w/ Cable Stop
$19.95
$23.69
Availability:
Available to Order
- Product SKU: JND-UST-540
- NSID: 45356
-
JND-UST-540
The Jonard Tools UST-540 cable stripping tool is designed to strip COAX, Network Cables, and Telephone Cables for quick and easy termination. This universal stripping tool features the following:
- Included blade cartridge (UST-240) provides a 2-level strip on RG59 and RG6 COAX Cables for F, BNC, and RCA connector termination
- High carbon steel blades last over 5,000 strips on each side
- Cable stop on one side of the cartridge ensures precise stripping without need to make adjustments
- Cartridge is reversible for ambidextrous use
- Adjustable stripping hole is used to strip CAT3/4/5E/6/6A PVC and Plenum network cables
- Cutter is included to cut all types of cables
- Separate stripping slot included for stripping Flat Cable & 4P/6P style cable
- Hook and Loop strip on bottom of the tool folds back the braided shield on the cable with ease
- Large finger loop provides smooth rotation during use
- Stripping action removes 1/4" of jacket and 5/16" of shield and dielectric, which exposes the center conductor
$19.95
Specifications
| Cable Type |
COAX, Network, Flat Telephone Cable |
|---|---|
| Cable Size |
RG-59/6 COAX, CAT3/4/5E/6/6A Network, Up to 1 cm wide Flat Cable |
| Dimensions | 4.92 in x 2.79 in x 0.95 in (12.48 cm x 7.07 cm x 2.4 cm) |
| Weight | 0.15 lb (66.284 g) |
| UPC # | 811490017696 |
