Kawneer - KW133622-17 - 1686 Concealed Exit Device - 3-6 Foot Door - RH / LHR - Aluminum
- $587.08
-
$704.50 - $587.08
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
The Kawneer 1686 Concealed Rod exit device is an exclusive to Kawneer customers. This exit device is UL Listed, is Hurricane Impact tested and Florida Product Approved. This device has the feature of rod adjustment without panel removal. Depression of the touchbar on the interior retracts the concealed rods from the transom bar and the threshold, allowing egress from the building. Upon closing, the top rod is released and frees the bottom rod to engage the threshold. The door is now relocked. A quick single point “dogging” feature in the housing deactivates the device and permits unrestricted traffic flow. Vertical rods and latch mechanisms are concealed in the vertical door stile. A 1-5/32" diameter mortised 5-pin cylinder with trim is required.
Dimensions:
- Centerline of touch bar to bottom of door: 40" (1,016)
- Height: 3-3/16" (81)
- Projection: 2-3/4" (70)
- Projection when dogged: 1-13/16" (46)
- Finish: Clear Aluminum
