Specifications
| Door Prep | Cross Bore 2-1⁄8”. Edge Bore 1”. |
| Latch face | 1” x 2 1⁄4”. |
| Backset | Adjustable to 2 3⁄8” or 2 3⁄4” standard. |
| Door Thickness | 1 3⁄8” - 1 3⁄4” doors standard. |
| Cylinder | 5-Pin Kiwkset Pin & Tumbler Cylinder |
| Faceplates | 1” x 2 1⁄4”. |
| Strikes | 1” x 2 1⁄4” full. |
| Bolt | 1” throw. |
| Door Handing | Reversible for right or left-hand doors. |
| Grade | ANSI/BHMA A156.2 Grade 3 |
| ADA | The interior turn piece meets 4.13.9 ADA requirements. |
