Details

| Door Prep | Cross Bore 2-1 �8". Edge bore 1". |
| Backset | Adjustable 2-3�8" or 2-3�4". UL functions 2-3�4" standard or 2-3�8" optional. |
| Door Thickness |
1-3�8" - 1-3�4� Doors standard. |
| Cylinder |
SmartKey Security or Pin & Tumbler |
| Faceplates | 1" x 2-1 �4" Specify round corner, square corner or drive-in. |
| Strikes |
2-1 �4� Full lip. Specify round corner or square corner. Other options available. |
| Bolt |
1 �2� Throw |
| ANSI/BHMA |
Grade 2 Certified |
| ADA | 200 and 488 functions satisfies section 4.13.9 ADA requirements. |
| UL | Meets 3-hour fire rating for all UL specific functions. |
