Details
Specifications
| Cover | Metal Cover |
| Finish | Aluminum |
| Arms | Regular Arm |
| Templating | Peel-n-Stick templates -2 1⁄4" x 5" mounting hole pattern |
| Handing | LH |
| Fasteners | Self reaming and tapping screws (SRT) |
| Size | Adjustable Spring Size, sizes 1-6 (Includes patented Green Dial) |
| Mounting | Hinge (Pull Side), Top jamb (Push Side), Parallel arm (push side) |
| Accessibility |
Available with less than 5.0 lbs. opening force on 36" door |
| Fluid | All weather liquid X fluid |
| Body construction | Cast iron body Full complement bearing 1 1⁄2" diameter piston Double heat treated pinion journal |
| Fire Rated | UL 10C 3 Hour Positive pressure |
| Certifications | Grade 1, ANSI, UL 10C, BAA |
| Manufacturer's Warranty | 30 Years |
Downloads
- Specifications
-
Pull/Parallel arm Installation Instructions
- Push/Top Jam arm Installation Instructions
