Details
| MAX. GATE WEIGHT | TB200 50 - 125 lbs. TB600 150 - 250 lbs. |
| MIN. GATE WIDTH | TB200 30" TB600 44" |
| MAX. GATE WIDTH | TB200 52" TB600 72" |
| MAX OPENING ANGLE |
100 Degrees |
| MIN. OPERATING TEMPERATURE |
15 Degrees Fahrenheit* |
| MAX. OPERATING TEMPERATURE |
122 Degrees Fahrenheit* |
| OPENING PRESSURE | TB200 3-7 lbs TB600 8-18 lbs. |
| HINGE ARRANGEMENTS | In-line or Offset |
| TYPE OF GATE MATERIAL |
Vinyl; Steel; Wood; Chain Link** |
| MATERIAL |
Steel |
| FINISH | Stainless Steel |
| WARRANTY | 1 Year |
Note: To retain product warranty & restrict gate opening angle, a gate stop must be installed (not included).
*Operation of the closer in temperatures below or above the minimum and maximum operating temperatures may result in improper operation or complete failure of the closer.
**In order to be mounted on chain link, a TB-LINX is required (not included).
