Details
Specifications
Electronic Specifications:
| Access Codes | Stores up to 49 PIN access codes |
| RFID/Fob key Access | Stores up to 999 MiFare RFID/Fob |
| Fingerprint Access | Stores up to 99 biometric fingerprints |
| Remotely Shareable Temporary Access | Unlimited access via the LocklyPro commercial app or LocklyOS |
| Visual and Audible | Exterior: LED (Red, Green) Interior: LED (Red) Configurable Lock/Unlock Audio Indicator |
| Communication Standards | BLE 4.2, Wi-Fi 2.4 GHz, RF433.92 MHz Advanced Encryption Standard (AES), 256-bit |
| Gateway Communication Range (Networked Solution) | Up to 98' (30m) BLE Up to 197' (60m) Wi-Fi Up to 164' (50m) RF433.92MHz Unobstructed open environment |
| Command Response | Responds to command from host in less than 3 seconds when linked to Lockly Wi-Fi Hub 0.2S on Fingerprint Recognition |
| Connectivity Options | LocklyPro Commercial app, LocklyOS, Matter Controller ALL in real-time communication |
| Available Signal Status | Battery Status via App Open/Close Door Status Bluetooth Connectivity Indicator Sensor LED (Red/Green) |
| Battery Life | AA Alkaline Batteries x 4 Up to 1 Year (offline mode) Up to 10 months (regular use with App & Sensor) |
| Operating Temperature | -4°F to 151°F (-20°C to 66°C) |
| Operating Humidity | 0 - 95% non-condensing |
Credential Specifications:
| Credential Technologies | RFID Card (13.56 MHz) BLE (2.4 GHz) Wi-Fi (2.4 GHz) Capacitive Sensor Patented PIN Genie Keypad |
| Standards | ISO 14443 |
| Maximum Read Range | RFID: up to 0.79" BLE: up to 98" (30m) Wi-Fi: up to 197" (60m) |
| RFID/Fob Compatibility | MiFare S50 |
| Mobile Compatibility | LocklyPro Commercial App BLE 4.2 LocklyOS, Matter |
Mechanical Certifications:
| Handing | Field Reversible |
| Materials | Premium Zinc Alloy chassis and escutcheon 45 mins Fire tested / Salt Resistant (200hrs test) |
| Door Thickness | 1-3/8" - 2" (35mm - 50mm) |
| Backset | Adjustable 2-3/8" or 2-3/4" (60mm or 70mm) 1" x 2-1/4" round corner faceplate |
| Strike | Latchbolt: 1-1/8" x 2-3/4" round corner. Dust box included |
| Bore | 2-1/8" (54mm) diameter Bore hole 1" (25mm) diameter latch hole |
| Physical Keys | SC1 Re-keying compatible, 2pcs included |
Certifications/Warranty
| Certification | UL 10B | UL 10C, FBC, ROHS, FC, ADA Compliant, NFPA 252 | CAN/ULC-S104, Intertek 5026048 |
| Warranty | Lifetime 24/7 Technical Support 2-years Limited Mechanical & Finish 2-years Limited Electronics |
What's Included:
- Latch 679L
- Installation Guide
- User Manual
- Welcome Card
- AA Alkaline Batteries x 4
- Drilling Template
- Activation Card
- RFID Key Tag x 3
- Physical Key x 2
- Secure Link Wi-Fi Hub
- Wired Door Sensor
- Bolt Assembly
- Mounting Plate
- Fixing Screws
- Strike Plate
