Details
| Lock Function | ANSI F86 Storeroom |
| Handing | Non-Handed |
| Door Thickness | 1-5/8” to 1-7/8” |
| Backset | 2-3/4″ standard, |
| Latch |
#1134, Front: 1-1/8” x 2-1/4” |
| Levers | Solid cast Zamac; w/ 1/2” return |
| Roses | Thru-bolted, spring loaded 2-#10 thru-bolts (Inside rose cover included) |
| Strike | #1145/32D |
| Cylinder | MARKS “C” keyway, 6 pin w/ 2 keys |
| Finish | 626 - 10B - Dark Oxidized Bronze |
| Certifications |
ANSI/BHMA Meets or exceeds A156.2-2011 4000 Series Grade 2 requirements UL Listed 3-hour fire rating ADA Meet Requirements of The Americans with Disabilities Act BAA Meet Guidelines of The Buy American Act CSFH Sentinel and Quest Lever Designs meet California State Reference Code (CSFH) |
| Manufacturer Warranty | Marks lifetime mechanical warranty |
Lock Function
Return Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact Marks USA directly at 1-800-645-9445 or visit their support page here. Once you have the ticket contact UHS Hardware for the return.
