Marks USA - 7NY92F-26D - New York Mortise Lever Lock - 26D - 1-1/4" X 8"- Dormitory - LH

In Stock
SKU: MRK-7NY92F-LH-26D
NSID: 26290

Get it shipped ! Order within:

Member Benefits

Get it shipped ! Order within:

Get an Extra Hour with

Learn More
$178.06
$213.67
$178.06

Combine security with style with the Marks New York 7 Series Mortise Locks. Perfect for Dormitories.

  • Satin Chrome
  • Solid Brass plates
  • Left Hand Mortise Lockset
  • American Lever Style
  • Solid brass cylinder - 2 keys

Call 1-800-878-6604 for Bulk / Dealer Pricing!
Description

Specifications

Trim Series 7 New Yorker Mortise Lever Lockset
Function Dormitory -The deadbolt is engaged or retracted by an outside key or an inside thumb-turn. When the deadbolt is engaged the outside grip is locked and will not retract the latchbolt. The latchbolt is retracted by the grip on either side as long as the deadbolt is retracted. When the deadbolt is engaged the inside grip simultaneously retracts both the deadbolt and the latch.
Cylinder C keyway cylinder with 2 keys
Bolt Cast alloy full 1” throw
Latch Solid brass 1/2” throw, reversible
Lock Front 1-1/4” x 8”, Flat
Door Thickness 1-5/8" to 2-1/4" standard.
Lock Specifications 9 Series (2-3/4" Backset)
Case High pressure cast Zamac, baked powder coat finish.

Diagram (Note Diagram Shows Deadbolt Models )
