Details
Specifications:
| Function | Cabinet Deadbolt lock |
| Cylinder | N Series: (equivalent to National D4291 4-pin system) |
| Keyed Alike | 101, 103, 107, 915, 51001, 51002, 51003, 51004, KD |
| Cylinder Length |
15/16" , 1-3/8" , 1-5/8" |
| Barrel Diameter | 7/8" |
| Bolt Length | Standard Length |
| Handing |
Optional Left Hand (KI) or Right Hand (KV) |
| Function | Key removable in locked position only |
| Body | Zinc Die Cast |
| Finish | Satin Chrome Plated |
| Includes | 2 keys, 12-3 angle strike, and lock mounting screws |
| Certifications | Passed ANSI/BHMA A156.11 Grade 1 performance requirements. Equivalent to E07041(200DW) |
