Olympus - 800S - Cabinet Drawer Deadbolt Lock - Key Retaining - S Series Schlage C Keyway - Optional Cylinder Length - Oil Rubbed Bronze - Optional Keying - Optional Handing - Grade 1 - UHS Hardware
Olympus - 800S - Cabinet Drawer Deadbolt Lock - Key Retaining - S Series Schlage C Keyway - Optional Cylinder Length - Oil Rubbed Bronze - Optional Keying - Optional Handing - Grade 1 - UHS Hardware

Olympus - 800S - Cabinet Drawer Deadbolt Lock - Key Retaining - S Series Schlage C Keyway - Optional Cylinder Length - Oil Rubbed Bronze - Optional Keying - Optional Handing - Grade 1

Available to Order
SKU: OLY-800KI10B-101-KA
NSID: 34946 34947 34953 34970 34971 34977 34948 34949 34951 34972 34973 34975

Please Note: This product ships within 2 Days

$60.45
$69.08
$60.45
Cylinder Length: 1-1/8"
Handing: Inverted
Keying: Keyed Alike - 101-KA

OLY-800KI10BXXXX (Regular Bolt)

S Series Schlage C Keyway Door Deadbolt Lock.

Olympus Lock manufactures institutional-grade cabinet locks that reflect the Company’s culture of design and ingenuity. The company pioneered rekeyable cabinet locks and holds numerous North American patents speaking to those inventions. By incorporating feedback from locksmiths at airports, casinos, schools, and hospitals, Olympus engineered its products to be both durable and easy to work with, making it the preferred choice of institutional locksmiths. The Company has been around for over three decades, is still family owned and operated, and boasts industry leading ship times.


Features:

  • S Series Schlage C Keyway
  • Cabinet drawer deadbolt lock
  • Key retaining
  • Easily rekeyable via set screw cylinder release mechanism
  • Passed ANSI/BHMA A156.11 Grade 1 performance requirements
  • Cylinder length: Optional 1-1/8" or 1-3/8"
  • Barrel diameter: 1-1/8"
Call 1-800-878-6604 for Bulk / Dealer Pricing!

Specifications:

Function Deadbolt drawer lock key retaining
Cylinder S Series: Schlage C Keyway Deadbolt
Keyed Alike KA 101,102
Cylinder Length
Optional 1-1/8" or 1-3/8"
Barrel Diameter 1-1/8"
Handing
Inverted or Vertical option
Function Key removable in locked position only
Body Zinc Die Cast
Finish Oil Rubbed Bronze
Includes For 1-1/8"barrel length locks:
- 10-350 plastic spacers (qty 2)
- 10-054 1/4" plastic bar strike
- 10-055 1/2" plastic bar strike
For 1-3/8"barrel length locks:
- 10-054 1/4" plastic bar strike
Certifications Passed ANSI/BHMA A156.11 Grade 1
performance requirements. Equivalent to
E07121 (700S) / E07041 (800S).
