Details
Specifications:
| ANSI/BHMA | Passed ANSI/BHMA A156.11 Grade 1 performance requirements. Equivalent to E07261/E07271 |
| Cylinder diameter | 1-1/8" |
| Across flats |
7/8" |
| Max. material thickness | 1-3/16" |
| Min. material thickness | 0.08" |
| Functions | Includes parts for key-retaining or nonkey-retaining function |
| Body | Zinc die cast |
| Finish | Satin Chrome 26D |
| Cylinder | Not included |
| Accepts | Schlage large format/full-size IC cylinders - Schlage Quad, Numbered Section, and Schlage Classic IC cores - Schlage Primus® and Everest large format IC cores - Mul-T-Lock large format IC cores |
| Compatible electronic cylinders |
VIDEX CyberLock LFIC cylinders |
| Included Accessories | 7788-PA-D actuator to operate lock without core 720-PL3 anti-rotation plate 720-3-1 short inverted cam 720-3-2 long vertical cam 720-CDLM lost motion cam shifter 720-CDDM key retaining door cam shifter 720-KR key retaining drawer cam shifter |
Downloads:
Reviews
Customer Reviews
Based on 1 review
100%
(1)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
We purchased this Olympus Cam Lock because we decided to move forward with an LFIC System for the efforts of cam lock jobs which ultimately give a better security outcome.
We absolutely love this piece of hardware from UHS Hardware so glad they offer it because it’s a must have item. We would recommend this product to anyone looking for a stronger more secure cam lock.
