Details
Specifications:
| Keying | Can be keyed together with other N Series locks |
| Rekeyable | Working top-slide, cylinder retainer staple and removable bezel ring make rekeying fast and easy |
| Retrofit | Replacement for HON F24/F28 style vertical file cabinet locks |
| Standard function | Key removable in locked or unlocked position |
| Body | Zinc die cast |
| Cylinder | Zinc die cast, pin tumbler |
| Includes | Brass mounting nut |
| Barrel diameter | 3/4" |
| Across flats | 5/8" |
| Finish | Satin Chrome 26D |
| Keyway | N Series (equivalent to National D4291 4-pin or D4292 5-pin system) |
| Keys | Includes 2 keys per lock |
