Details
Metal Reader Features
- 125 kHz prox cards supported
- Anti-vandal and waterproof design
- IP65 fully-potted
- Zinc Alloy metal body
Specifications
| Input: | Frequency: 125 KHZ Read Range: up to 1.9” |
| Output: | Wiegand protocol Cable Distance: Wiegand 500’ (22 AWG) |
| Environmental: | Temperature: -4 ~ +122 F or -20 ~ +50 C Humidity: 0 - 95% relative humidity, non-condensing Protection Rating: IP65 |
| Enclosure: | Dimensions: (W x H x D) 1.88” x 4.05” x 0.86” Weight: 0.94 lbs / 15.1 oz / 430 g |
| Power: | 10.8 - 12V DC (Linear power supply recommended) |
| Manufacturer’s Limited Warranty | One to five-year warranty against defects in materials and workmanship. For full details visit prodatakey.com. |
Package Contents -
- Card Reader (1)
- Punch Sticker (1)
- L Wrench (1)
- Self Tapping Screws (3)
- Expansion Rubber Bungs (3)
This item is available for purchase ONLY for low voltage and access control professional installers. Non certified professional installers do not qualify for ANY technical support from PDK. Additionally, the manufacturer's warranty is ONLY available for professional certified access control installers
