Login to view price
Or Call 1-800-878-6604 for Dealer Prices!

Availability: Available
  • Product SKU: PDK-1DE
  • NSID: 24260
  • PDK-1DE

    Easily add single doors to a cloud node.

    The single io controller is used for adding doors to a cloud node one door at a time or expanding an existing pdk system. With the option of network, PoE, or wireless connectivity, the single io is the most flexible controller on the market. Each unit is equipped with a fully supervised power circuit that monitors input, output, battery voltage, and overall controller health. Users receive important system notifications via text and email.

    Model PN: 1DE - Single IO Door Controller (Ethernet)


Single IO Features

Scalability Whether you need three doors or a thousand, the single io controller also allows you to scale the system to just the right size. Also, with the flexibility of our WiMACTM wireless, you can add more doors anytime, or anywhere.

Fully Supervised Never be caught off guard again. Pdk.io intelligently monitors the network and wireless connectivity of each controller in your system and alerts you if any issues arise.

Plug n’ Play Connectivity All io devices were designed to be plug n’ play. That means they’re super easy to install right out of the box. It’s easy to add in any io device no matter how large the job is, and you can quickly scale a system to any size. A cloud node can connect with up to a thousand doors on a single platform.

Fully Supervised Never be caught off guard again. Pdk.io intelligently monitors the network and wireless connectivity of each controller in your system and alerts you if any issues arise.

Two Reader Inputs Two reader inputs are ideal for applications where both read in and read out is a security requirement. Know exactly when users enter and exit a premise. The second reader input can also be assigned to trigger automated events.

Network, PoE, Wireless Choose from three flexible connectivity options that fit any application. The single io is built for ultra-low bandwidth consumption and easily connects to existing or dedicated networks. Easily expand a systems wireless coverage (via network) using the ethernet gateway

IMPORTANT: A PDK -  Cloud Node is required to operate the Single io, Eight io, and Eight io+ door controller products.

Specifications

 Connections: Removable Screw-down Terminals Power Supply Input Industrial-grade 2A Form-C Relays (1 Door / 1 Aux) Reader Input (2) Input A (Door Position Sensor) Input B (Request To Exit)
Communication Options: Ethernet
Environmental: Temperature: -20º ~ +60º C or -4º ~ +140º F
Humidity: 0 - 95% relative humidity non condensing
Enclosure: Dimensions (W x H x D) 6.5” x 7.5” x 2” Metal lockable security can (indoor use only) Lock sold separately
Compliance: Conforms to UL 294 (excludes 1DPOE)
Power: 12-24V AC/DC Input 12VDC 1.5A *Battery-Backed Output Powers readers and other door hardware directly from the bus *Power supply and battery not included
Manufacturer’s Limited Warranty One to three-year warranty against defects in materials
and workmanship.


Package Contents - Cloud Node includes the main panel and Single io door controller

  • Single Door Controller (1)
  • Battery Leads (1)
  • Screws (2)
  • Diode (1)
  • Labels (2)
  • Transformer (1)
  • Jumpers (3)

This item is available for purchase ONLY for low voltage and access control professional installers. Non certified professional installers do not qualify for ANY technical support from PDK. Additionally, the manufacturer's warranty is ONLY available for professional certified access control installers

Quick Start Guide

Online Manual



PDK-1DE

Easily add single doors to a cloud node.

The single io controller is used for adding doors to a cloud node one door at a time or expanding an existing pdk system. With the option of network, PoE, or wireless connectivity, the single io is the most flexible controller on the market. Each unit is equipped with a fully supervised power circuit that monitors input, output, battery voltage, and overall controller health. Users receive important system notifications via text and email.

Model PN: 1DE - Single IO Door Controller (Ethernet)

Single IO Features

Scalability Whether you need three doors or a thousand, the single io controller also allows you to scale the system to just the right size. Also, with the flexibility of our WiMACTM wireless, you can add more doors anytime, or anywhere.

Fully Supervised Never be caught off guard again. Pdk.io intelligently monitors the network and wireless connectivity of each controller in your system and alerts you if any issues arise.

Plug n’ Play Connectivity All io devices were designed to be plug n’ play. That means they’re super easy to install right out of the box. It’s easy to add in any io device no matter how large the job is, and you can quickly scale a system to any size. A cloud node can connect with up to a thousand doors on a single platform.

Fully Supervised Never be caught off guard again. Pdk.io intelligently monitors the network and wireless connectivity of each controller in your system and alerts you if any issues arise.

Two Reader Inputs Two reader inputs are ideal for applications where both read in and read out is a security requirement. Know exactly when users enter and exit a premise. The second reader input can also be assigned to trigger automated events.

Network, PoE, Wireless Choose from three flexible connectivity options that fit any application. The single io is built for ultra-low bandwidth consumption and easily connects to existing or dedicated networks. Easily expand a systems wireless coverage (via network) using the ethernet gateway

IMPORTANT: A PDK -  Cloud Node is required to operate the Single io, Eight io, and Eight io+ door controller products.

Specifications

 Connections: Removable Screw-down Terminals Power Supply Input Industrial-grade 2A Form-C Relays (1 Door / 1 Aux) Reader Input (2) Input A (Door Position Sensor) Input B (Request To Exit)
Communication Options: Ethernet
Environmental: Temperature: -20º ~ +60º C or -4º ~ +140º F
Humidity: 0 - 95% relative humidity non condensing
Enclosure: Dimensions (W x H x D) 6.5” x 7.5” x 2” Metal lockable security can (indoor use only) Lock sold separately
Compliance: Conforms to UL 294 (excludes 1DPOE)
Power: 12-24V AC/DC Input 12VDC 1.5A *Battery-Backed Output Powers readers and other door hardware directly from the bus *Power supply and battery not included
Manufacturer’s Limited Warranty One to three-year warranty against defects in materials
and workmanship.


Package Contents - Cloud Node includes the main panel and Single io door controller

  • Single Door Controller (1)
  • Battery Leads (1)
  • Screws (2)
  • Diode (1)
  • Labels (2)
  • Transformer (1)
  • Jumpers (3)

This item is available for purchase ONLY for low voltage and access control professional installers. Non certified professional installers do not qualify for ANY technical support from PDK. Additionally, the manufacturer's warranty is ONLY available for professional certified access control installers

Quick Start Guide

Online Manual
