*Discontinued* Rosslare - MDW11GR - Wireless Access Control Door Interface - 24 V Power Supply
Out of Stock
SKU:
ROS-MD-W11GR
NSID:
25396
- $610.71
-
$732.85 - $610.71
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
The MD-W11GR utilizes Bi-Directional RF data communication and Rolling Code protocol to relay Wiegand 26-bit and other formats including PIN code messages, lock, door relay, tamper, door monitor and REX signals between the Near and Far interface units.
Features
- Bi-directional RF data communication
- Supports PIN codes and card formats, such as Wiegand 26 bit, 32 bit, and PIN code 6 bit
- Lock and door relay commands
- Tamper, door monitor, and REX messages between the controller and the interface unit
- Rolling Code to increase security
- Four different RF channels to prevent collisions
- Built-in charger for up to 12VDC, 7Ah backup battery on the Far unit
- Transfers proximity card information and LED control, reader tamper, lock relay commands, REX, and door monitor events between the coupled units.
- Suitable for indoor use.
- Available in 869 MHz (H) and 433.92 MHz (G) bands
- The NEAR unit is powered from the controller's power supply. The
FAR unit is powered by a local wall transformer. A built-in
charger provides battery backup.
- $610.71
-
$732.85 - $610.71
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
Description
x| Input Voltage | 12-24 AC / 15-24 VDC |
| Battery Charger | 12V sealed Lead-Acid, up to 7Ah (Far Unit) |
| Input Current |
Standby: 70mAh Max: 160mA |
| Max Range |
300 meters (985 feet) |
| Response Time | Up to 500ms with Rosslare’s AC-215 controller and reader. |
| Output Relays | 5A Form C relay |
| Communications | Bi-directional RF, narrow band. Fast anti-collision, rolling code protocol with data protection. |
| Operating Environment | Indoor Use |
| Operating Temperature | -10°C to 50°C (14°F to 122°F) |
| Dimensions | 13 x 8.7 x 3.2 cm / 5.1 x 3.42 x 1.26 inch |
