Availability: Available to Order
  • Product SKU: SCH-L9050P-17L-626
  • NSID:
  • SCH-L9050P-17L-626


    The Schlage L Series has long been the benchmark for mortise locks. Beyond strength and security – it offers tremendous flexibility to allow it to meet the needs of most every application

    More Information Below


    Please Note: This product has a lead time
    Get it shipped
    Today!
    Order within
    00 Hrs
    00 Mins
    00 Secs
Lock Function

04 - Office  Entry - Inside always free, Outside locked by inside thumbturn and keyed - No Deadbolt

Handing Non-Handed
Door Thickness 1 3/4" (44 mm)
Cylinder 30-001 cylinder keyed different, with 2 keys
Backset 2 3/4" (70 mm) only
Latch
3/4" (19 mm) throw stainless steel latch with anti-friction tongue
Lever 17 Lever 4.625" x 2.875"
03 Lever  4.75" x  2.813"
Material Stainless Steel / Zinc
Case size 4-7⁄16" x 6-1⁄16" x 1"
Strike ANSI curved lip strike 1-1/4" x 4-7/8" x 13/16" lip to center with dust box standard
Fire Rated 3 Hour Fire Door
Certifications
ANSI/BHMI Certified A156.13-2012
Commercial Grade 1
Lock Body Mortises Inside the Edge of the Door
UL/cUL Listed UL 10C
Manufacturer Warranty 3 year limited mechanical


Downloads

SCH-L9050P-17L-626


The Schlage L Series has long been the benchmark for mortise locks. Beyond strength and security – it offers tremendous flexibility to allow it to meet the needs of most every application

More Information Below

Lock Function

04 - Office  Entry - Inside always free, Outside locked by inside thumbturn and keyed - No Deadbolt

Handing Non-Handed
Door Thickness 1 3/4" (44 mm)
Cylinder 30-001 cylinder keyed different, with 2 keys
Backset 2 3/4" (70 mm) only
Latch
3/4" (19 mm) throw stainless steel latch with anti-friction tongue
Lever 17 Lever 4.625" x 2.875"
03 Lever  4.75" x  2.813"
Material Stainless Steel / Zinc
Case size 4-7⁄16" x 6-1⁄16" x 1"
Strike ANSI curved lip strike 1-1/4" x 4-7/8" x 13/16" lip to center with dust box standard
Fire Rated 3 Hour Fire Door
Certifications
ANSI/BHMI Certified A156.13-2012
Commercial Grade 1
Lock Body Mortises Inside the Edge of the Door
UL/cUL Listed UL 10C
Manufacturer Warranty 3 year limited mechanical
