Schlage

Schlage - ND70BD - Commercial Lever Set - Classroom Lock - Less SFIC - Satin Chrome - Optional Levers - Fire Rated - Grade 1

Schlage - ND70BD - Commercial Lever Set - Classroom Lock - Less SFIC - Satin Chrome - Optional Levers - Fire Rated - Grade 1

In stock
SKU SCH-ND70BD-ATH-626 NSID 29898
$414.54$497.45On Sale You save $82.91 (17%)
Get it shipped Today! Order within:
Lever



The Schlage ND is extremely versatile and is regularly used in healthcare, education, government, office, retail and other commercial applications. With 31 mechanical functions, the ND's range spans from the simple (non-locking passage) to complex (double-cylinder security) to specialized (school time-out lock). Because the ND uses an ANSI 161 door prep, commonly used across cylindrical locks, it is ideal for both new construction and retrofit applications.

Features

  • Significantly exceeds ANSI/BHMA A156.2 requirements for Grade 1 cylindrical locks
  • Prepped for SFIC cylinder formats
  • Fire Rated for 3 Hours
  • Cylinder NOT INCLUDED
  • TLR - Tubular Lever Style
  • Support for 10 non-Schlage cores
  • Outside lever locked and unlocked by key.
  • Inside lever always free for immediate egress.
Call 1-800-878-6604 for Bulk / Dealer Pricing!
View full details

Details

Specifications

    Chassis
    Material Stainless Steel / Zinc
    Door Thickness 1 5⁄8" to 2 1⁄8"
    Trim
    Lock Function Classroom Lock - Outside lever locked and
    unlocked by key.
    Handing Non-Handed
    Lever Multiple Lever Options
    Finish 626 - Satin Chrome
    Latches
    Backset 2 3⁄4"
    Faceplate Size 1 1⁄8" x 2 1⁄4"
    Bolt 1⁄2" throw
    Strike ANSI Curved Lip: 1 1⁄4" x 4 7⁄8" x 1 3⁄16"
    Keying
    Formats 3 Schlage
    Access security 6-Pin
    Cylinder SFIC Prep Less Core Cylinder not Included
    Fire Rated 3 Hour Positive pressure
    Certifications
    		 ANSI/BHMA, ICC, UL/cUL
    Manufacturer Warranty 10 years mechanical, 1 year wired electrified


    Dimensions ATHENS

    Dimensions RHODES


    Dimensions LATITUDE

    Downloads
