*Discontinued* Seagate / Skyhawk / Surveillance Hard Drive / 4TB HDD / HDD-ST4000VX000
- $143.55
-
- $143.55
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
The New Generation SV Drive
The industry's first surveillance-optimized hard drive precision-tuned for high write surveillance workloads operating 24x7 Capacities up to 8TB support 64 cameras per drive and 8+1 drives per system Engineered for workloads of 180TB/year, three times that of desktop drives Low power consumption and startup current to minimize heat and vibration emission, improving long-term drive reliability Tarnish-resistant components to help protect drive from environmental elements, increasing field reliability Customize power settings for incremental savings during system downtime without compromising time to record Reliable performance in multi-drive systems with support from RV sensors Optional 3-year +Rescue Data Recovery Service plan to help protect against data loss from viruses, software issues or mechanical and electrical breakdowns
Best-Fit Applications
- NVR
- Embedded SDVR
- Hybrid SDVR
- Surveillance DVR
- $143.55
-
- $143.55
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
Description
xSpecifications |
|
| Capacity | 4TB |
| Standard Model Numbers | ST4000VX000 |
| +Rescue Model Numbers | ST4000VX002 |
| Interface | SATA 6Gb/s |
| Cache | 64MB |
| Bytes per Sector | 4096 |
| Performance | |
| R/V (Rotational Vibration) Sensor | Yes |
| Drive bays supported | 8+ |
| Cameras Supported | Up to 64 |
| Max Sustainable Transfer Rate | 180MB/s |
| +Rescue Data Recovery Service | |
| 3-Year Option With +Rescue Model | Yes |
| Voltage | |
| Voltage Tolerance, Inc. Noise (5V) | ±5% |
| Voltage Tolerance, Inc. Noise (12V) | ±10% |
| Power Management | |
| Startup Power (12V, A) | 1.8 |
| Average Operating Power | 5.6W |
| Idle Average (W) | 4W |
| Standby Mode | 0.5W |
| Sleep Mode | 0.5W |
| Environmental/Temperature | |
| Operating (ambient, min) | 0°C |
| Operating (drive case, max) | 70°C |
| Nonoperating (ambient, min) | -40°C |
| Nonoperating (ambient, max) | 70°C |
| Reliability | |
| Tarnish Resistant1 | Yes |
| Load/Unload Cycles2 | 300,000 |
| Nonrecoverable Read Errors per Bits Read, Max | 1 per 10E14 |
| MTBF (Hours) | 1,000,000hr |
| Power-On Hours | 8,760 |
| Warranty, Limited (years) | 3 |
| Physical | |
| Height (mm/in) | 26.11mm/1.028in |
| Width (mm/in, max) | 101.6mm/4in |
| Depth (mm/in, max) | 146.99mm/5.787in |
| Weight (g/lb) | 610g/1.345lb |
| Carton Unit Quantity | 20 |
| Cartons per Pallet / Cartons per Layer | 40 / 8 |
1 Drives with Rotational Vibration sensors can be used in systems with 8+ drive bays. Drives without Rotational Vibration are ideal for systems with 8 or fewer drives.
