Details
| Operating Voltage | 12VDC |
| Current Draw | 280mA@12VDC |
| Latch Throw | 1/2" (13mm) |
| Static Strength | 1,000-lb (454kg) |
| Endurance | 250,000 Cycles (Factory tested) |
| Operating Temperature | 14°~120° F (-10°~49° C) |
| Operating Humidity | 0~85% (Non-condensing) |
| Dimensions | Stainless Steel No-Cut Plate: 2-3/4"x1-1/8"x15/16" (70x28x24 mm) |
Downloads:
