TownSteel - E-Genius 4000 - Interconnected Electronic Touch Keypad Lock - Storeroom - RFID - 5 1/2" - Quest Lever - Left handed - Matte Black - Grade 1 - UHS Hardware
TownSteel - E-Genius 4000 - Interconnected Electronic Touch Keypad Lock - Storeroom - RFID - 5 1/2" - Quest Lever - Left handed - Matte Black - Grade 1 - UHS Hardware
TownSteel - E-Genius 4000 - Interconnected Electronic Touch Keypad Lock - Storeroom - RFID - 5 1/2" - Quest Lever - Left handed - Matte Black - Grade 1 - UHS Hardware

TownSteel - E-Genius 4000 - Interconnected Electronic Touch Keypad Lock - Storeroom - RFID - 5 1/2" - Quest Lever - Optional Handing - Matte Black - Grade 1

Available to Order
SKU: TNS-EG4ST-QLH622-55NSC
NSID: 45656 45655

Please Note: This product has a lead time

Handing: Left Handed

The e-Genius 4000 is the only keyless double lock providing the ability to lock and unlock an interconnected dead-latch and deadbolt with a single lift of the lever from inside and outside of your home. Access your home with keyless freedom and convenience using a highly responsive, 12-key illuminated touch and fingerprint resistant keypad programmable with up to 400 user user codes interchangeable with RFID keycards/stickers. Mechanical key override lock is available as an extra back-up.



  • Latchbolt can always be locked so that when shutting the door, it is automatically locked
  • Extended deadbolt
  • Left Hand, Right Hand
  • Quest Lever
  • Including 2 RFID Key Cards and 2 RFID stickers
Call 1-800-878-6604 for Bulk / Dealer Pricing!



Function Storeroom
Door Thickness:  1-3/4”
Backset 2-3/8″ – 2-3/4″ adjustable
Lock Body 5.5"
Trim
Clutched
Latch bolt: 1/2“ throw stainless steel deadlocking
Faceplate 1" x 2-1/4"
Deadbolt Strike 1-1/8″ x 2-3/4″ radius corners with security underplate
Key Override Yes
Cylinder 6 pin Schlage C keyway, standard
Power Supply
4 AA Alkaline batteries - No Hard wiring
Battery Life
Up to 1 year
Finish 626 - US26D - Satin Chrome, 622 - US19 - Flat Black Coated
Handing Left Handed, Right Handed
Certifications ANSI/BHMA A156.2 -- A156.2-2011 Grade 1 certified
UL/ULC -- UL 10C 3-hour rated
BAA -- Meets guidelines of the Buy American Act
ADA --- Meets requirements of the Americans with Disabilities Act
RoHS -- Meets requirements of EU RoHS Directive 2002/95/EC
Manufacturer Warranty 2-year limited for electronic
5-year limited for finish
10-year limited for mechanical
