Details
Specifications
| Application |
For all types of single or double door with a mullion |
| Door Thickness |
1-3/4″-2-1/4″ |
| Backset | 2-3/4″ standard, |
| Door Width |
36″ device for up to 3′ wide opening |
| Operation | Pressing push bar retracts latch bolt when not dogged |
| Dogging | Flat Key standard |
| Strike |
106 type Dull Blank, 2 pieces shims included |
| Latch bolt |
Stainless Steel, deadlocking, 3/4″ throw |
| Fasteners |
For 1-3/4″ – 2-1/4″ thick wood and metal door applications |
| Handing | Non-handed |
| Finish | US32D |
| Trim | Available in 200 and 300 series, sold separately |
| Centerline from Finished Floor | 39-5/8″ |
| Certifications |
ANSI/BHMA - A156.3-2008 Grade 1 Certified UL - UL 305 panic hardware listed BAA - Meets requirements of the Buy American Act ADA - Meets guidelines of the Americans with Disabilities Act |
| Manufacturer Warranty | 1-year limited for electronic 5-year limited for finish 10-year limited for mechanical |
Downloads
Return Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact Townsteel directly at 877-858-088, [email protected] or visit their support page here. Once you have the ticket contact UHS Hardware for the return.
