Trine - 3275VRP-LC-ALUM - 3000 Series - Electric Strike - Vertical Rod Solution - Fire Rated ANSI - Grade 1

Available to Order
SKU: TRN-3275VRP-LC-ALUM
NSID: 36571

Please Note: This product has a lead time

$273.65
$314.29
$273.65

SMALLEST ELECTRIC STRIKE FOR USE WITH VERTICAL RODS

Features:

  • Includes Trine's 4-pin patented anchoring pin system.
  • Metal installation template included for faster more accurate installation.
  • 1/16" spacer plate provided.
  • 1/8" Horizontal Adjustment
  • BHMA GRADE 1 - Heavy Duty
    - 500,000 + life cycles
    - Solid stainless steel latch and locking mechanism
Call 1-800-878-6604 for Bulk / Dealer Pricing!

Works with these vertical rod devices:

  • Sargent 97/68
  • Arrow 3700/S1150/600
  • Cal-Royal 9860V/F9860V
  • Town Steel ED1200F
  • Von Duprin 33/35
  • Von Duprin 98/99 (Without the Deadlocking option - Von Duprin Latches without the deadlock are available and easy to replace on the door)

    Volts Current/Amps Ohms (Ω) Duty Sound Wire Color
    12DC 0.743/0.298 13 Ω Intm./Cont. Silent Red
    24DC 0.397/0.170 13 Ω Intm./Cont. Silent Red
    12AC 0.715/0.277 13 Ω Intm./Cont. Silent Red
    24AC 0.378/0.173 13 Ω Intm./Cont. Silent Red
