Details
Technical Specification
| Video/Audio Input | |
| IP Video Input | 4-ch(only IP up to 12ch), each channel up to 4K |
| Two-way Audio Input | 1-ch, RCA |
| Network | |
| Incoming Bandwidth | 56Mbps |
| Outgoing Bandwidth | 64Mbps |
| Remote Users | 128 |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE |
| Video/Audio Output | |
| HDMI/VGA Output | HDMI: 3840 x 2160/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Recording Resolution | 8MP Lite/5MP Lite/4MP Lite /1080P/960P/720P/960H/D1/4CIF/CIF |
| Audio Output | 1-ch, RCA |
| Synchronous Playback | 8-ch |
| SATA | 1 SATA interface |
| Capacity | Up to 8TB for each disk |
| External Interface | |
| Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel: 2 x USB2.0 |
| Serial Interface | 1 x RS485 |
| General | |
| Power Supply |
12V DC Power Consumption: ≤ 8 W( without HDD ) |
| Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) |
| Dimensions (W×D×H) | 260mm ×240mm× 46mm (10.2" × 9.4"×1.8") |
| Weight (without HDD) | 1.1 Kg ( 2.42lb |
Downloads
Data Sheet
Quick Start Guide
User Manual
