Von Duprin - 3347AEO - Panic Rim Exit Device - Narrow Stile Pushpad - 36" - Night Latch - Field Reversible - Less Trim - Dark Bronze Aluminum - Grade 1

Available to Order
SKU: VNDP-3347AEO-3-313
NSID: 67829

Please Note: This product ships within 2 Days

$1,815.56
$2,178.67
$1,815.56

The 33A/35A Series devices are narrow stile heavy-duty push pads commonly used in higher education, K-12 schools, hospitals, hospitality, and government buildings among others.

Architectural design elements differ slightly between the 33A and the 35A. The 35A Series device has a smooth mechanism case, while the 33A Series has a grooved mechanism case.

Call 1-800-878-6604 for Bulk / Dealer Pricing!

Specifications

Device lengths 3' 2'4" to 3' (660mm to 914 mm) door size
Device centerline
from finished floor

39 13/16" (1006 mm)

Center case
dimensions
8 3/16" x 1 9/16" x 2 13/32" (208mm x 40mm x 62mm)
Mechanism case
dimensions
2 1/4" x 2 1/4" (57mm x 57mm)
Projection push bar

Pushbar Neutral – 3 13/16" (97 mm)
Pushbar Depressed – 3 1/16" (78 mm)

Latch bolt Deadlocking anti-friction top & bottom bolt 5/8" (16mm) throw
Fasteners Includes 1-3/4" (44mm) – 2 1/4" (57mm) wood & metal doors
#325 SNB furnished standard for EO (exit only device)
Handing Field Reversible
Finish Dark Bronze Aluminum
Dogging feature Hex key dogging standard
Certifications ANSI/BHMA A156.3 2014 Grade 1 certified
ANSI/UL 305
CAN/ULC-S132



 Downloads

Catalog

Installation Instructions



Please Note: Bulk price rates are available! Call us at 1-800-878-6604.

Note: Bulk price rates are available! Call us at 1-800-878-6604.

Compatible With

Note: Bulk price rates are available! Call us at 1-800-878-6604.
