Details
Specifications:
| Parameter | Value |
|---|---|
| Model | DL-855P28B-S7 |
| Image Sensor | 1/2.7” CMOS |
| Effective Pixels | 2592 * 1944 |
| Min. Illumination |
Color: [email protected] (AGC ON) B/W: [email protected] (AGC ON |
| Flash / DDR | 128Mb / 1Gb |
| IR LED No. | 4 |
| IR Distance | 30m |
| S/N Ratio | > 52dB |
| Lens | |
| Lens Type | Motorized |
| Mount Type | Board-in |
| Focal Length | 3.6mm~10.8mm |
| Aperture | F1.6 - 3.3 |
| FOV | 29.8°~93.5° |
| Optical Zoom | 3X |
| Compression | H.265 / H.264 |
| Resolution | 5MP(2562x1944) / 4MP (2688 x 1520) / 3MP (2304 x 1296) / 1080P (1920 x 1080) / 1.3MP (1280 x 960) / 720P (1280 x 720) |
| Bitrate Control | CBR / VBR |
| Bitrate | H.265: 3Mbps - 8Mbps H.264: 3Mbps - 8Mbps |
| Multi-Streaming | Main Stream: 5MP@25fps/ 4MP@25fps / 3MP@25fps /1080P@25fps / 960P@25fps / 720P@25fps Sub Stream : D1@25fps / VGA@25fps / CIF@25fps Third Stream: CIF@25fps |
