ABRITES - AVDI - TN00F - Full Toyota special functions set TN008, TN009, TN010, TN013, TN014 and TN015

Available to Order
SKU: ABRITES-TN00F
NSID: 59218

Please allow 24 to 48 hours to process

$4,200.00
$5,040.00
$4,200.00

TN008 is a key programming solution for Toyota/ Lexus/ Scion vehicles. This functionality allows you to perform key learning in ALL KEYS LOST situations for mechanical 128 bit H-type keys (with DST-AES transponders).

Using the TN008 function and the ZN069 Toyota mechanical key (H-type) adapter set you will be able to perform the ALL KEYS LOST procedure without removing any immobiliser-related modules from the vehicle.

With the TN009 you can perform reset of the ID Code Box available for ALL Toyota vehicles including the latest generation produced after 2018 and for ID Code Boxes without an external EEPROM.

The reset of the ID Code Box opens up many possibilities for those working on Toyota vehicles, mainly due to its location and the long time it takes for the vehicle to be dismantled until the ID Code Box is removed. These include:

  • Key programming situations - for vehicles manufactured after 2018, where key programming requires a new set comprising an ID Code Box, Smart System and keys, users can use also second hand Smart systems (with available keys) as a plug and play solution once the ID Code Box has been reset.
  • Smart system defect - in this case, just like in key programming situations all modules would have to be replaced. The reset of the ID Code Box allows you to exchange only the Smart system and the keys and both new and second hand Smart systems can be used (second hand smart systems need to have keys available).
Call 1-800-878-6604 for Bulk / Dealer Pricing!

TN010 is a license dedicated to mileage recalibration for Toyota vehicles with VDO/Continental dashboard with micro controller 70F35xx.

Models include but are not limited to:

  • Auris 2 (2016+)
  • Avensis (2016+)
  • CH-R
  • Corolla (2016-2019)
  • Tacoma

    Special function TN013 will give users a complete key programming solution for the full range of Lexus vehicles produced after 2018.

    • ALL KEYS LOST
    • Spare key programming completely by OBDII

    Supported vehicles include:

    • Lexus RX
    • Lexus RXL
    • Lexus ES
    • Lexus LS
    • Lexus UX

    N.B. Please note that you will require an AVDI interface with an Active AMS and a ZN003 PROTAG V2 Programmer in order to use this special function. Absolutely no tokens required.

    Thе TN014 license expands the key programming capabilities of the ABRITES software for the latest generations Toyota vehicles, equipped with Tokai Rika Smart System with BA type HT-AES keys.

      Functionalities:

      • Spare key programming
      • ALL KEYS LOST

      Including the models, already supported in the TN011 legacy license:

      • Corolla 2018+
      • Camry 2018+
      • Highlander 2018+
      • Mirai 2020+

      No additional subscriptions (dealer access) are required to complete the key programming procedure.

      This solution covers said models, regardless of the market on which they are offered - all versions of the models are supported (US, European, UK, Asia). Smart system reset is NOT needed, nor a connection to Toyota servers.

      Depending on the transponder type TA68 DST-AES TA64 HT-AES emulator is needed. CB012 will also be required for internal CAN-BUS connection to the vehicle.


      N.B. Please note that you will require an AVDI interface with an Active AMS and a ZN003 PROTAG V2 Programmer in order to use this special function. Absolutely no tokens required.

      The TN015 is a step further in the development of key programming solutions for Toyota vehicles by ABRITES. Our team has created a license for a selection of vehicles, manufactured after 2020, equipped with a Denso Smart System with BA type DST-AES keys.

      Functionalities:

      • Spare key programming
      • ALL KEYS LOST

      Supported models:

      • Sienna 2020+ (XL40)
      • Harrier/Venza 2020+ (XU80)
      • Tundra 2021+ (XK70)
      • Land Cruiser 2021+ (J300)
      • RAV4 Facelift 2022+ (XA50)

      Including the models, already supported by the TN012 legacy license:

      • CH-R 2018+
      • Prius 2018+
      • Avalon 2018+
      • RAV4 2018+

      Depending on the transponder type TA68 DST-AES TA64 HT-AES emulator is needed. CB012 will also be required for internal CAN-BUS connection to the vehicle.


      N.B. Please note that you will require an AVDI interface with an Active AMS and a ZN003 PROTAG V2 Programmer in order to use this special function. Absolutely no tokens required.


      ALL SALES OF ABRITES PRODUCTS HARDWARE AND SOFTWARE ARE FINAL!

      Note: You will require anAVDI interface with an Active AMS and a ZN003 PROTAG V2 Programmer in order to use this special function. Absolutely no tokens required.
