ABRITES - MN00F - Full Mercedes-Benz Special Functions Set For Passenger Vehicles. Includes MN030, MN032, MN033, MN034, MN035, MN037, and MN038 Licenses
Available to Order
SKU:
ABRITES-MN00F
NSID:
75813
- $5,520.00
-
$5,580.00 - $5,520.00
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
The Full Mercedes-Benz cars package includes the MN030, MN032, MN033, MN034, MN035, MN037, and MN038 licenses. Below you can see what each one of them covers as functionalities.
1. MN030 – Odometer Calibration & Cluster Module Replacement (FBS4)
- OBDII-based mileage adjustment and virgin/adapt cluster modules
- Blocks synchronization between cluster and EZS/EIS on IC213-equipped FBS4 vehicles
- Retrofit support: analogue → digital dials
- Supports models: W213, W205, W222, W217, W238, W253, W257, W463, W447 (with IC213), and related models
Description
x2. MN032 – FBS4 Control Module Virginization/Personalization
- Designed from the ground up for FBS4 (DAS) modules
- Features: virginize modules, read/write personalization, module activation, read module status, VIN programming
- Supports via OBDII: MED17, EDC17, SID310, Delphi‑CRD3, CR40/41/42/43/6/60/61, MED40/41, MED177/1773/1775, CRR1/1+, CRD3S2, hybrid starter generators, MRD1/MRG1/CRR2/EMS71 via bench or distribution-box setups
- Bench support (with ZN051/ZN030): DSM, VGS-DCT, VGS-NAG3, MRD1/MRG1 (pre-2021); DSM via ABPROG connection
3. MN033 – Electronic Steering Lock (ELV/ESL) Fault Clearing
- Clears “ELV Component Fault” that prevents vehicle start
- Works on all FBS4 vehicles with ESL/ELV modules
- Can be done in-vehicle or on‑bench; ZN151 Distribution Box recommended
4. MN034 – FBS4 Personalization Expert
- Expert-level personalization for all virgin FBS4 generation modules using internal CAN‑BUS
- Removes limitations from production year changes or missing old units (e.g., MED177/1775, CR40/60/61, etc.)
- Enables ECU personalization via OBDII when no prior data is available
- Intended to complement MN032; partial coverage for W223/W206 requiring a future adapter
5. MN035 – VGS4‑NAG2 TCU Virgin & Personalization via ABPROG
- Works with VGS4‑NAG2 7G‑Tronic FBS4/DAS4 TCUs using ABPROG
- Features: read FBS4 data, virginize TCU, write personalization via internal CAN‑BUS (also via internal CAN‑BUS with MN034 license)
- Requires: ZN030 ABPROG programmer, AVDI, and active AMS
6. MN037 – IC177 Cluster Calibration (Bench)
- Calibrates IC177 dashboard clusters (2018–2023 vehicles) via PCB bench mode
- Adjusts mileage, blocks EZS sync; does not affect EZS module
- Supports A-Class, B-Class, GLA, CLA, GLB, EQA, EQB, CLS, AMG GT 4‑door, and similar IC177 vehicles
- Requires ZN085 RH850/V850 Programmer, ZN092 adapter, CB501 cable; bench soldering/un‑soldering involved; wiring diagrams included
7. MN038 – IC223 / IC177M Cluster Calibration (Bench, 2020+)
- Similar to MN037 but tailored for newer clusters IC223 (2020+) and IC177 M (2023+) with Visteon R7F701529 BGA processors
- Bench-mode mileage calibration and EZS sync block, using emulator, no EZS module handling
- Supported models include: S-Class (W223), C‑Class (W206/S206/V206/X206), GLC (X254/C254), CLE (C236/A236), and other IC223 vehicles—plus newer vehicles with IC177 M
- (A/B/CLA/GLA/GLB/EQA/EQB/CLS/GLE/GLS/AMG GT facelift)
- Requires ZN085 Programmer, ZN092 adapter, EM019 adapter, CB501 cable; bench PCB solder/un‑solder, wiring diagrams included
| License | Functionality | Vehicles / Modules | Hardware Required |
|---|---|---|---|
| MN030 | Odometer reset & cluster virgin/adapt (OBDII) | FBS4 dashboards (IC213/IC222) | AVDI + AMS |
| MN032 | FBS4 module virginization/personalization | ECUs, DSM, TCUs | ZN051, ZN030, CB cables |
| MN033 | Clears ESL/ELV faults | All FBS4 ESL/ELV | ZN151 |
| MN034 | Expert personalization via internal CAN | All FBS4 modules | AVDI + MN032 |
| MN035 | Virgin/personalize VGS4‑NAG2 TCU | 7G‑Tronic TCUs | ZN030, AVDI + AMS |
| MN037 | IC177 cluster calibration (PCB bench) | 2018–2023 IC177 dashboards | ZN085, ZN092, CB501 |
| MN038 | IC223/IC177 M calibration (2020+) | Newer clusters post-2020 | ZN085, ZN092, EM019, CB501 |
